Ajax Wireless Voice Module with AI in Black

SKU
AJ-SPEAKERPHONE-B
Brands: AJAX
€208.41
Tax included
% Discount for professionals
AJAX
Availability: In stock
5 days

SpeakerPhone Jeweller Wireless Voice Module for Alarm Verification

The Ajax Wireless Voice Module with AI in Black enables an Alarm Receiving Centre (ARC) to listen to what is happening and communicate with occupants immediately after an alarm. Voice verification helps operators distinguish a genuine intrusion from a false alarm and coordinate a faster, more appropriate response.

SpeakerPhone Jeweller provides full-duplex two-way audio through Ajax’s proprietary VoRF protocol. It features AI-powered voice optimisation for noise suppression, a 3 W speaker delivering up to 103 dB, voice audibility at distances of up to 10 metres and wireless communication with the hub at up to 1,700 metres in open space.

It operates within the Ajax system with the Hub 2 4G Jeweller alarm control panel, Hub 2 Plus Jeweller and Hub Hybrid 4G. It is an accessory for new installations or compatible system expansions, not a spare part, and requires telephony configuration by the security company to communicate with the ARC.

The operator can use the module to warn an intruder that the police are on their way or provide instructions during a fire, medical emergency or other critical event. It is designed for indoor installation, has an IP50 protection rating and does not work as a standalone intercom; its AI optimises voice transmission but does not analyse or detect alarms.

Reference: AJ-SPEAKERPHONE-B

-
+

Extended information about the Ajax Wireless Voice Module with AI in Black

Practical applications of the Ajax Wireless Voice Module with AI in Black

Example 1. Intrusion verification in a closed retail premises

When an Ajax detector triggers outside business hours, the hub activates SpeakerPhone Jeweller so the Alarm Receiving Centre operator can listen to the premises and speak to anyone inside. The installer can position the module in a central location to support alarm verification and allow the operator to issue a direct voice warning before coordinating a police response.

Example 2. Guiding occupants during an emergency

In an office or home connected to a security company, the operator can use the Ajax voice module to provide instructions following a fire alarm, panic button activation or medical emergency. Full-duplex communication helps the operator assess the situation, guide the people on site and coordinate assistance without requiring occupants to have access to a telephone.

Package contents of the Ajax Wireless Voice Module with AI in Black

  • 1 × SpeakerPhone Jeweller in black
  • 1 × SmartBracket mounting panel
  • 4 × pre-installed CR123 batteries
  • 1 × installation kit
  • 1 × quick start guide

Technical specifications Ajax Wireless Voice Module with AI in Black

Feature Specification
Brand Ajax
Model SpeakerPhone Jeweller
SKU AJ-SPEAKERPHONE-B
Product type Wireless voice module for alarm verification
Product line Baseline
Colour Black
System Ajax security system
Audio communication Full-duplex two-way audio
Audio protocol Ajax proprietary VoRF protocol
AI voice optimisation Configurable through an Ajax app
Audio optimisation functions Clear voice transmission, background noise suppression and improved audibility over distance
Speaker output power 3 W
Speaker volume Up to 103 dB, with three volume settings
Voice audibility Up to 10 m
Audio frequency range 200 Hz to 16 kHz
Conversation duration Adjustable up to 10 minutes per call session
Hub communication protocol Jeweller
Wireless communication range Up to 1,700 m in open space
Operating frequency bands 866.0–866.5, 868.0–868.6, 868.7–869.2, 905.0–926.5, 915.85–926.5 and 921.0–922.0 MHz, depending on the sales region
Compatible hubs Hub 2 (4G) Jeweller, Hub 2 Plus Jeweller and Hub Hybrid (4G)
Firmware updates OTA
Anti-sabotage protection Dismantling alarm, device authentication, communication loss detection and data encryption
Main power supply 4 pre-installed CR123 batteries
Battery life in standby mode Up to 3 years
Battery life in conversation mode Up to 12 hours
Optional external power supply 12 V DC, 1 A; the batteries operate as a backup power source
Installation Indoor installation using SmartBracket
Pairing QR code scanning
Configuration Remote control and configuration through Ajax apps
Recommended installation height 1.6 m
Protection rating IP50
Operating temperature 0 °C to +40 °C
Operating humidity Up to 75%
Dimensions 112 × 112 × 41.5 mm
Weight 270 g
Included components SpeakerPhone Jeweller, SmartBracket, four pre-installed CR123 batteries, installation kit and quick start guide



More Information
More Information
EAN 4823114060861
Hight 0.000
Length 0.000
Width 0.000
SECURITY - SYSTEM Complements
SEGURIDAD - SERIE Accessories
Color Black
Product Brand AJAX
Reviews
Write Your Own Review
You're reviewing:Ajax Wireless Voice Module with AI in Black
Your Rating
Product Attachment
File Label Size Download
pdf Ficha Técnica Módulo de Voz Inalámbrico con IA en color Negro de Ajax 1.8 MB Download
