DTT Televes kit with maximum gain, 20 m cable, 2 F connectors and economical power supply

SKU
TDT0052
Brands: Televes
€98.81
Tax included
Availability: In stock
24/48 Hours

Televes DAT BOSS 42 dBi DTT Kit with Cable and 24 V Power Supply

The Televes TDT0052 DTT kit includes the main components required for a reliable terrestrial television installation: DAT BOSS antenna, 24 V power supply, 20 metres of RG6 coaxial cable and two F connectors.

The Televes DAT BOSS 149921 antenna operates across the 470 to 694 MHz UHF band, channels 21 to 48, providing 17 dBi in passive mode or up to 42 dBi with BOSSTech activated. Its automatic gain control is especially useful for installers working with weak or fluctuating terrestrial TV signals.

The kit also includes a Surmedia SMB301 24 Vdc, 100 mA power supply with two RF outputs, two F connectors and a 20-metre roll of Televes 435501 RG6 coaxial cable featuring triple shielding and Class A+ screening performance. It is suitable for new DTT installations or for fully renewing an existing reception system; it is not merely a replacement part.

A balanced solution for single-family homes and small distribution networks with up to two branches, combining a high-gain antenna with the essential connection components. The mast, mounting bracket, TV outlets and any additional distribution accessories are not included.

Reference: TDT0052

-
+

Extended information about the Televes maximum-gain DTT kit with 20 m cable, 2 F connectors and economical power supply

Practical applications of the Televes maximum-gain DTT kit

Example 1: New DTT reception system for a home with a weak signal

An installer can use this kit to deploy a UHF reception system in a single-family home where the available signal requires a wide dynamic range. Powered at 24 V by the SMB301 power supply, the DAT BOSS antenna activates BOSSTech and provides up to 42 dBi with automatic gain control. The 20 m coaxial cable is suitable for a short indoor downlead, while the two RF outputs allow the signal to be connected to two branches.

Example 2: Complete replacement of an ageing domestic TV reception system

When the antenna, downlead and power supply have deteriorated, the technician can replace the main reception components together. The DAT BOSS antenna can operate in active or passive mode, while the Televes 435501 coaxial cable provides triple shielding and Class A+ screening to reduce interference. The two included F connectors allow the supplied RG6 cable to be terminated without purchasing them separately.

Package contents of the Televes maximum-gain DTT kit

  • 1 × Televes DAT BOSS UHF LTE700 antenna, reference 149921.
  • 1 × 20 m roll of Televes 435501 RG6 coaxial cable, white and intended for indoor use.
  • 2 × 6.6 mm F connectors for RG6 coaxial cable, reference CONF.
  • 1 × Surmedia SMB301 24 Vdc, 100 mA power supply with two RF outputs.

Technical specifications Televes maximum-gain DTT kit

Feature Specification
Kit SKU TDT0052
Product type Terrestrial television reception and distribution kit
Application New DTT-UHF installations or complete renewal of a domestic reception system
Antenna Televes DAT BOSS 149921 with BOSSTech and LTE700 filtering
Frequency band UHF, 470 to 694 MHz
Channels 21 to 48
Antenna gain 17 dBi with BOSS off; up to 42 dBi with BOSS on
Gain regulation Automatic in BOSS mode according to the output level
Noise figure 1.2 dB in BOSS mode
Antenna power requirement 12 to 24 Vdc; maximum current consumption of 40 mA
Beamwidth 30°
Front-to-back ratio Greater than 20 dB
Compatible mast diameter 20 to 50 mm
Antenna dimensions 1,142 × 736 × 560 mm
Antenna weight 2,086 g
Included cable Televes 435501, 20 m, 75 Ω RG6, white
Cable construction Copper-clad steel conductor, aluminium braid and triple shielding
Screening class Class A+; screening effectiveness greater than 95 dB at 1 GHz
Cable standard EN 50117-2-4
Reaction to fire Euroclass Eca
Outer diameter and sheath 6.8 mm; white PVC sheath for indoor use
Typical cable attenuation 0.17 dB/m at 698 MHz; 0.31 dB/m at 2,150 MHz
Included connectors Two 6.6 mm screw-on F connectors for RG6 cable
Power supply Surmedia SMB301, 24 Vdc and 100 mA maximum current
Power supply outputs Two RF outputs with F connectors
Power supply installation Indoor installation; power supplied to the antenna through the coaxial cable



More Information
EAN 8400520000016
Hight 0.000
Length 0.000
Width 0.000
DTT System DTT Reception
SERIES DTT Pasive
Type DTT 4G, DTT 5G
Entorno Exterior
Orientation Directive
Gain High
Dipole Active
LTE compatible Yes
Supply required Yes, included
Feed Power 12 Vc, 24 Vc
Product Brand Televes
