Single Masts

Masts for holding antennas

If you are thinking of buying a mast for the DTT antenna, radio antenna or parabolic you are in the appropriate section. In our online store we have different lengths of masts with different thicknesses and thicknesses, each suitable for a situation.

If you need a short mast for a single antenna you can purchase a mast of 1 meter or 1.5 meter. In case you need to put more than one antenna on the same mast you will need a longer mast to have enough length to carry this task over. It is recommended to leave a space of at least 1 meter between antenna and antenna. For example: tdt antenna above, a meter, and FM antenna below, plus an extra meter for the wall fasteners, which are usually masts squares or masts claws.

Note that we call the masts by their three measures:

  • Length: (1 meter, 1.5 meter, 2.5 meters, or 3 meters)
  • Diameter: (35 mm, 40 mm and 45 mm)
  • Steel thickness: (1.5 mm or 2 mm)

If you want to join two or more masts you have to look at the diameter of the mast that is the same. Masts of different diameters do not fit together.

Buying a mast is easy. You only have to go to the roof where you are going to place it and see if with a short mast it would be enough for the antenna to see the repeater directly, or if you have any obstacle to pass to measure how much mast height you need to surpass the obstacle. Then you have to buy a longer mast or think of joining two masts.

There are situations where a greater height is needed, for these situations the masts can be short and turrets have to be used. The proper turret can reach the height we want.

Whenever two masts are mounted we recommend the use of winds to hold the top mast and do not cramp the antenna. We have a wind kit that includes everything you need and you can also buy the parts of the winds separately.


9 Items

Set Descending Direction
per page
  1. Mast 2,5m high and 35mm in diameter
    SKU: ROV61046
    In stock
    €15.72 Tax included
  2. Galvanized Mast 1.5m x 35mm Engel
    SKU: ENGAC0715E
    In stock
    €18.53 Tax included
  3. Mast 2.5 m. Carraqueado, 35 mm diameter, 1 mm thick.
    SKU: TEL3008
    In stock
    €18.90 Tax included
  4. Mast 1 meter x Ø 35 mm x 1mm Thickness Televes
    SKU: TEL242001
    In stock
    €23.04 Tax included
  5. Mast of 2.5 meters x 40 mm diameter x 2 mm thick Televes
    SKU: TEL3009
    On request
    €25.14 Tax included
  6. Mast 3 m. Carraqueado, Ø 40 mm, 2 mm thick.
    SKU: TEL3072
    On request
    €28.42 Tax included
  7. Mast 35 mm 1,5 m
    SKU: TEL2407
    On request
    €29.85 Tax included
  8. Mast Length 3m Diameter 40mm Rover
    SKU: ROV61050
    In stock
    €37.45 Tax included
  9. Mast of 3 meters long x 45 mm x 2 mm Televes
    SKU: TEL3010
    In stock
    €55.90 Tax included
