main product photo

Hikvision 2MP 2.8mm ColorVu PoE IP Dome Camera with Intelligent Detection

SKU
HWI-D121H-C(2.8mm)
Brands: Hikvision
€26.92
Tax included
% Discount for professionals
Hikvision
Availability: In stock
24/48 Hours

Hikvision 2MP 2.8mm ColorVu PoE IP Dome Camera with Intelligent Detection

The Hikvision HWI-D121H-C(2.8mm) Dome IP Camera is a compact, lightweight and discreet solution for improving security in homes, residential communities, shops, offices or protected indoor areas. Its dome format is especially useful when the camera needs to blend better into the environment and remain less visible than other video surveillance formats. In addition, it features intelligent human and vehicle detection, helping to identify relevant events and reduce false alarms caused by insignificant movements.

Its 2 MP Full HD resolution allows it to capture clear images, while its motion detection helps identify relevant activity in the monitored area. This camera allows access points and passage areas to be monitored both day and night, thanks to its infrared illumination with a range of up to 20 metres.

It includes image enhancement functions such as Digital WDR, BLC, HLC and 3D DNR, which help provide a more stable image in scenes with backlight, reflections or changing lighting conditions. It also allows adjustment of saturation, brightness, contrast, sharpness, gain and white balance from compatible client software or browser, such as Chrome 57.0+, Firefox 52.0+ or Edge 89+.

Designed for new IP video surveillance installations, the HWI-D121H-C is easy to install via PoE, using a single network cable to transmit both data and power. This improves cable organisation, provides a cleaner installation and can reduce installation time. It also supports up to 6 simultaneous live view channels and up to 32 users, making centralised supervision easier.

Reference: HWI-D121H-C(2.8mm)

-
+

Extended information about the Hikvision 2MP Fixed 2.8mm IP Dome Camera IR 20m Motion Detection PoE

Practical applications of the Hikvision 2MP Fixed 2.8mm IP Dome Camera IR 20m Motion Detection PoE

Example 1. Discreet surveillance in an office, shop or residential community:

In an office, shop, reception area, entrance hall or common area, the HWI-D121H-C allows access points and transit areas to be monitored with a more discreet visual presence. Its dome format helps the camera blend better into the environment, which is very useful when security is required without the device being too noticeable. Thanks to its Full HD resolution and 2.8 mm lens, it offers a wide view of the scene. In addition, its IR range of up to 20 metres allows surveillance to be maintained even in low-light conditions.

Example 2. Centralized monitoring with several camera points:

In installations with several IP cameras, the HWI-D121H-C allows up to 6 channels of simultaneous live view, making it easier to monitor different areas from the same environment. This improves security and enables more centralized supervision, especially in shops, residential communities or small offices with several areas to control. It also supports up to 32 users, with administrator, operator and user levels. The installer can integrate it with Hik-Connect, iVMS-4200 or systems with a compatible NVR.

Key features of the Hikvision HWI-D121H-C(2.8mm) IP Dome Camera

  • ColorVu technology allows colour images to be obtained even in low-light conditions.
  • H.265+ compression helps optimize storage and reduce bandwidth consumption on NVR recorders or compatible systems.
  • Its fixed 2.8 mm lens offers a wide field of view, suitable for access points, corridors, reception areas, shops and common areas.
  • PoE IEEE 802.3af power supply allows data and power to be transmitted through a single network cable, making installation easier.

Package contents of the Hikvision 2MP Fixed 2.8mm IP Dome Camera IR 20m Motion Detection PoE

  • Hikvision HWI-D121H-C(2.8mm) IP dome camera.
  • The remaining included accessories, such as screws, wall plugs, mounting template, quick guide or connectors, should be physically confirmed before publishing them in Magento.

Technical specifications of the Hikvision 2MP Fixed 2.8mm IP Dome Camera IR 20m Motion Detection PoE

Feature Specification
Brand Hikvision
Series HiWatch Series
Model HWI-D121H-C
SKU / Variant HWI-D121H-C(2.8mm)
Camera type Fixed IP dome camera
Image technology ColorVu
Image sensor 1/2.9” Progressive Scan CMOS
Maximum resolution 1920 × 1080
Resolution 2 MP
Shutter speed 1/3 s to 1/100,000 s
Minimum illumination Colour: 0.01 Lux @ F2.2, AGC ON / B/W: 0 Lux with IR
Day / night IR cut filter
Angle adjustment Pan 0° to 355° / Tilt 0° to 75°
Lens type Fixed lens
Focal length 2.8 mm
2.8 mm field of view Horizontal 101° / Vertical 56° / Diagonal 118°
Lens mount M12
Iris Fixed
Aperture F2.2
2.8 mm depth of field 0.8 m to infinity
DORI 2.8 mm Detection 44 m / Observation 17 m / Recognition 8 m / Identification 4 m
IR illumination Yes
IR range Up to 20 m
Smart IR Yes
IR wavelength 850 nm
Main Stream 50 Hz 25 fps at 1920 × 1080 / 1280 × 720
Main Stream 60 Hz 30 fps at 1920 × 1080 / 1280 × 720
Sub Stream 50 Hz 25 fps at 640 × 480 / 640 × 360
Sub Stream 60 Hz 30 fps at 640 × 480 / 640 × 360
Main Stream video compression H.265+ / H.265 / H.264+ / H.264
Sub Stream video compression H.265 / H.264
Video bitrate 32 Kbps to 8 Mbps
Bitrate control CBR / VBR
Network security Password protection, complex password, watermark, HTTP authentication, audit log and MAC authentication
Simultaneous live view Up to 6 channels
API ISAPI, SDK
Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, UDP, QoS
Users Up to 32 users
User levels Administrator, operator and user
Software / App iVMS-4200, Hik-Connect
Browser IE 10/11 for plug-in live view; Chrome 57.0+, Firefox 52.0+ and Edge 89+ for local service
WDR Digital WDR
SNR ≥ 52 dB
Day/night switch Day, night, auto and schedule
Image enhancements BLC, HLC, 3D DNR
Image settings Saturation, brightness, contrast, sharpness, gain and white balance
Ethernet interface 1 RJ45 10/100 Mbps self-adaptive
Basic events Motion detection and exception
Event actions Notification to surveillance centre
12 VDC power supply 12 VDC ±25%, 0.4 A, maximum 4.8 W
Power connector Ø5.5 mm coaxial jack
Reverse polarity protection Yes
PoE power supply IEEE 802.3af, Class 3
PoE consumption Maximum 6.5 W
Material Plastic
Dimensions Ø110.8 mm × 85.2 mm
Package dimensions 163 × 75 × 75 mm
Weight Approx. 240 g
Weight with packaging Approx. 380 g
Operating temperature -10 °C to 40 °C
Operating humidity 95% or less, non-condensing
Languages English, Ukrainian
General functions Heartbeat, anti-banding, mirror, password protection and email reset
IP/IK protection Not indicated in the attached datasheet
Anti-corrosion protection No specific anti-corrosion protection
Recommended use New IP video surveillance installations indoors or in protected areas
Available models HWI-D121H-C(2.8mm)(B) / HWI-D121H-C(4mm)(B)
More Information
More Information
EAN 6942160427058
Hight 0.100
Length 0.100
Width 0.100
Technology IP
Usar stock disponible No
Product Brand Hikvision
Camera Type Domo
Optic Type Fixed
Color White
Alimentación 12VDC/PoE
