Coaxial Cable Cu/CCA Eca Indoor PVC Black (100m)
€61.67
Tax included
Coaxial Cable CXT Cu/CCA Euroclass Eca Indoor PVC Black (100m) Televes 2139
75Ω Coaxial Cable with internal conductor made of Copper (Cu), Copper Clad Aluminum (CCA) mesh and Black PVC sheath for indoor routes.
This cable offers 2 shielding layers of Class B. It is Euroclass Eca rated for non-propagation of flame in the event of fire.
Coaxial cable for indoor distribution of TV-SAT signals (5-2300 MHz).
Televes
24/48 Hours
Coaxial Cable CXT Cu/CCA Euroclass Eca for Indoor in Black (100m)
What are the main characteristics of the Televes 2139 Coaxial Cable?
- Copper inner conductor and copper-clad aluminium braid
- Eca Euroclass
- Black-colour external PVC sheath
- 75 Ohm characteristic impedance
What technical specifications does the Televes 2139 Coaxial Cable have?
| Type | CXT | |||
| Standard | EN 50117-2-4 | |||
| EuroClass | Eca | |||
| Class | B | |||
| Inner conductor | Ø mm | 1 | ||
| Material | CU | |||
| Res. Ohm/Km | <23 | |||
| Dielectric | Ø mm | 4,8 | ||
| Material | PEE | |||
| Overlapped foil | Copper + Polyester | |||
| Braid | Material | CCA | ||
| Dimensions (Ncx Nsx Ø) | 16 x 3 x 0,12 | |||
| Res. Ohm/Km | <35 | |||
| Coverage % | 35 | |||
| Anti-migrating film | No | |||
| Petrol-Jelly | No | |||
| Outer sheath | Ø mm | 6,6 | ||
| Material | PVC | |||
| Minimum bending radius | mm | 33 | ||
| Screening attenuation @ 1GHz | dB | >75 | ||
| Capacitance | pF/m | 55 | ||
| Impedance | Ohm | 75 | ||
| Transfer impedance (5-30MHz) | mOhm/m | ≤15 | ||
| Velocity ratio | % | 82 | ||
| Attenuations (dB/m) | ||||
|---|---|---|---|---|
| Frequency (MHz) | ||||
| 5 | 0,01 | |||
| 47 | 0,05 | |||
| 90 | 0,06 | |||
| 200 | 0,09 | |||
| 500 | 0,14 | |||
| 800 | 0,18 | |||
| 1000 | 0,2 | |||
| 1350 | 0,24 | |||
| 1750 | 0,28 | |||
| 2050 | 0,3 | |||
| 2300 | 0,31 | |||
Televes
24/48 Hours
| EAN | 8424450101278 |
|---|---|
| System | RG6 |
| Serie | 100m |
| Entorno | Interior |
| Color | Black |
| Cobertura Exterior Cables | PVC |
| Conductor Interno Cables | Copper (Cu) |
| Material Malla Coaxial | Copper Clad Aluminum (CCA) |
| Product Brand | Televes |
Write Your Own Review
| Icon | Label | Size | Download |
|---|---|---|---|
|
TEL2139B Ficha Técnica | 144.5 KB | Download |
