main product photo

TP-Link Smart Switch with Energy Monitoring

SKU
TL-TAPOS110E
Brands: Tplink
€27.32
Tax included
% Discount for professionals
Tplink
Availability: In stock
1 to 7 days

Tapo S110E Smart Switch Module

The TP-Link Smart Switch with Energy Monitoring is a compact module designed to turn conventional lights, appliances and electrical circuits into smart devices. The Tapo S110E allows remote control through the Tapo app, voice assistants and compatible platforms, making it a practical choice for upgrading existing electrical installations.

This module works with 2.4 GHz Wi-Fi and Bluetooth, and supports Matter, Apple Home, Alexa, Google Assistant, Samsung SmartThings and IFTTT. It is intended for new smart home installations or domotic upgrades, not as a specific spare part, and is especially useful for installers who need remote control, scheduling and automation scenes in residential or small professional projects.

The Tapo S110E supports both wet contact and dry contact modes, so it can be used with powered electrical loads as well as potential-free contact systems. This makes it suitable for automating lighting, sockets, boilers, garage doors, heating systems or irrigation, always within the electrical limits specified by the manufacturer.

In addition, it offers energy monitoring in wet contact mode with AC input, scheduling, auto-off timer and Bluetooth control without Wi-Fi for setup or reconnection through the Tapo app. It can be combined with other Domotics solutions or Smart Plugs to expand a connected installation.

Reference: TL-TAPOS110E

-
+

Extended information about TP-Link Smart Switch with Energy Monitoring

Practical applications of the TP-Link Smart Switch with Energy Monitoring

Example 1. Smart control of a centralized heating boiler:

A single-family home has an old oil-fired boiler activated by a traditional wall thermostat that works by closing a circuit, also known as dry contact. By installing the Tapo S110E directly on the boiler’s control terminal block, the module acts as the main switch for the system. Thanks to its Matter compatibility, the relay can be linked to Tapo temperature sensors placed in different rooms; when the home’s average temperature drops below 19 °C, the module closes the circuit to turn the heating on, and automatically switches it off when it reaches 21 °C, helping optimize fuel consumption without replacing the boiler.

Example 2. Lighting or electrical load control with energy monitoring:

In wet contact mode, the TP-Link Tapo S110E smart switch module can be used to control lights, sockets or electrical appliances within the load limits specified by the manufacturer. In this mode, with AC input, it provides energy monitoring, scheduling and remote management from Alexa, Google Assistant, Siri, SmartThings or the Tapo app.

Package contents of the TP-Link Smart Switch with Energy Monitoring

  • Tapo S110E x 1
  • Jumper wire x 3
  • Wire labels
  • Quick start guide

Technical specifications TP-Link Smart Switch with Energy Monitoring

Feature Details
Product Smart switch module
Brand TP-Link / Tapo
TDTprofesional SKU TL-TAPOS110E
Manufacturer model Tapo S110E
Installation type New installations or smart home upgrades
Main function Remote control, automation and energy monitoring
Working modes Dry contact and wet contact
Connectivity 2.4 GHz Wi-Fi IEEE 802.11b/g/n and Bluetooth
Compatibility Matter, Apple Home, Alexa, Google Assistant, Samsung SmartThings and IFTTT
App control Tapo app
Voice control Alexa, Google Assistant, Siri and Samsung SmartThings, depending on the compatible ecosystem
Scheduling Schedules, timer and smart scenes
Bluetooth control Setup and reconnection via Bluetooth even without Wi-Fi
Energy monitoring Available in wet contact mode with AC input
Zero-crossing detection Yes, according to the manufacturer datasheet
Wet contact AC mode Input 100-250 V~ 50/60 Hz; output 100-250 V~
Maximum AC load 10 A resistive, 1.5 A motor, 150 W LED
Wet contact DC mode Input 24-60 V DC
DC output 24-30 V 10 A; 30-48 V 1.5 A; 48-60 V 1 A
Dry contact mode Compatible with potential-free contact systems, according to TP-Link wiring instructions
Dry contact output 100-250 V~ 10 A resistive, 1.5 A motor, 150 W LED; 5-30 V 10 A; 30-48 V 1.5 A; 48-60 V 1 A
Dimensions 44.7 x 33.9 x 16.1 mm
Recommended use Indoor use only
Operating temperature Pending confirmation by version: PDF states -15 °C to 35 °C; TP-Link website states -20 °C to 40 °C
Operating humidity 10% to 90% RH, non-condensing
Certifications CE, RoHS
Usage warning Do not use in damp environments or outdoors
More Information
More Information
EAN 8885021370873
Hight 0.060
Length 0.030
Width 0.010
Color White
Automation Button / Switch
Usar stock disponible No
Product Brand Tplink
