| Interface |
4 PoE ports RJ45 + 1 UpLink port |
|
| Port speed |
4 x 10/100, 1 x 10/100 Mbps |
|
| Power supply |
Up to 30 W per port (35 W for the complete device) |
|
| PoE features |
According to norm IEEE 802.3at PoE+ / IEEE 802.3af PoE |
|
| Power |
DC 48 V / 800 mA máx. |
|
| Operating temperature |
0º C - 40º C |
|
| Dimensions |
83.1 (D) x 27.6 (H) x 105 (W) mm |
|
| Brand |
Hikvision |
|
| Model |
DS-KD8003-IME1(B) |
|
| Operating system |
Linux |
|
| Image sensor |
Low Illumination 2 Mpx IR |
|
| Image Functions |
BLC / WDR / DNR |
|
| Viewing angle |
H: 146º, V: 82º, D: 180º |
|
| Audio |
Bidirectional audio with microphone and speaker |
|
| Keypad |
Mechanical button with LED backlit name-tag |
|
| Outputs |
2 x lock relay, 1 x module output, 1 x DC 12 V / 500 mA max. |
|
| Inputs |
4 x auxiliary inputs (output button, feedback, door sensor), 1 x tamper |
|
| Remote access |
Software iVMS-4200
Hik-Connect mobile application |
|
| Network interface |
Ethernet 10/100 BaseT / SIP Protocol 2.0 |
|
| Modular |
Compatible with Hikvision modular boards |
|
| Power |
DC 12 V / 850 mA máx. / PoE (IEEE 802.3af) |
|
| Degree of protection |
Suitable for exterior IP65 |
|
| Material |
Plastic |
|
| Temp. operation |
-40º C ~ +60º C |
|
| Dimensions |
98 (H) x 100 (W) x 42 (D) mm |
|
| Weight |
360 g |
|
| Brand |
Hikvision |
|
| Model |
DS-KH6320-WTE1 |
|
| Operating system |
Linux |
|
| Screen type |
7" color touch-screen TFT |
|
| Screen resolution |
1024 x 600 |
|
| Inputs |
8 x configurable alarm inputs, 1 x RS485 |
|
| Outputs |
2 x relay outputs |
|
| Audio |
Two-way audio with integrated microphone and loudspeaker
Noise reduction and echo cancellation |
|
| Memory |
MicroSD card slot (up to 128 GB) |
|
| Connection |
Ethernet 10/100 BaseT / RTSP / SIP Protocol 2.0 / WiFi 802.11 b/g/n (only for connection to app via P2P) |
|
| Remote access |
Software iVMS-4200
Hik-Connect mobile app |
|
| Power |
DC 12 V / 1 A max. / IEEE802.3af PoE |
|
| Temp. operation |
-10º C ~ +55º C |
|
| Dimensions |
140 (H) x 200 (W) x 15 (D) mm |
|
| Weight |
355 g |
|
| Slave monitors |
Switch
|
| |
Interface |
4 PoE ports RJ45 + 1 UpLink port |
| |
Port speed |
4 x 10/100, 1 x 10/100 Mbps |
| |
Power supply |
Up to 30 W per port (35 W for the complete device) |
| |
PoE features |
According to norm IEEE 802.3at PoE+ / IEEE 802.3af PoE |
| |
Power |
DC 48 V / 800 mA máx. |
| |
Operating temperature |
0º C - 40º C |
| |
Dimensions |
83.1 (D) x 27.6 (H) x 105 (W) mm |
| |
DS-KD8003-IME1(B)
|
| |
Brand |
Hikvision |
| |
Model |
DS-KD8003-IME1(B) |
| |
Operating system |
Linux |
| |
Image sensor |
Low Illumination 2 Mpx IR |
| |
Image Functions |
BLC / WDR / DNR |
| |
Viewing angle |
H: 146º, V: 82º, D: 180º |
| |
Audio |
Bidirectional audio with microphone and speaker |
| |
Keypad |
Mechanical button with LED backlit name-tag |
| |
Outputs |
2 x lock relay, 1 x module output, 1 x DC 12 V / 500 mA max. |
| |
Inputs |
4 x auxiliary inputs (output button, feedback, door sensor), 1 x tamper |
| |
Remote access |
Software iVMS-4200
Hik-Connect mobile application |
| |
Network interface |
Ethernet 10/100 BaseT / SIP Protocol 2.0 |
| |
Modular |
Compatible with Hikvision modular boards |
| |
Power |
DC 12 V / 850 mA máx. / PoE (IEEE 802.3af) |
| |
Degree of protection |
Suitable for exterior IP65 |
| |
Material |
Plastic |
| |
Temp. operation |
-40º C ~ +60º C |
| |
Dimensions |
98 (H) x 100 (W) x 42 (D) mm |
| |
Weight |
360 g |
| |
DS-KH6320-WTE1
|
| |
Brand |
Hikvision |
| |
Model |
DS-KH6320-WTE1 |
| |
Operating system |
Linux |
| |
Screen type |
7" color touch-screen TFT |
| |
Screen resolution |
1024 x 600 |
| |
Inputs |
8 x configurable alarm inputs, 1 x RS485 |
| |
Outputs |
2 x relay outputs |
| |
Audio |
Two-way audio with integrated microphone and loudspeaker
Noise reduction and echo cancellation |
| |
Memory |
MicroSD card slot (up to 128 GB) |
| |
Connection |
Ethernet 10/100 BaseT / RTSP / SIP Protocol 2.0 / WiFi 802.11 b/g/n (only for connection to app via P2P) |
| |
Remote access |
Software iVMS-4200
Hik-Connect mobile app |
| |
Power |
DC 12 V / 1 A max. / IEEE802.3af PoE |
| |
Temp. operation |
-10º C ~ +55º C |
| |
Dimensions |
140 (H) x 200 (W) x 15 (D) mm |
| |
Weight |
355 g |
| |
Slave monitors |
It is not possible to use the Android DS-KH9310 and DS-KH9510 monitors as slaves |
