Hikvision DS-3E0516R-O 16-Port RJ45 1Gbps 12W Switch

SKU
DS-3E0516R-O
Brands: Hikvision
€53.83
Tax included
% Discount for professionals
Hikvision
Availability: On request
1 to 7 days

Hikvision DS-3E0516R-O 16-Port RJ45 Unmanaged Gigabit Switch

The HikvisionUnmanaged Gigabit Ethernet switch with 16 RJ45 10/100/1000 Mbps ports. is a robust, efficient solution designed for networks with many wired devices. Its 16 ports make it possible to centralise the connection of computers, printers, NVRs, IP cameras, access points, TVs, workstations or other Ethernet devices in a single unit, helping to keep the network more organised, stable and easier to expand.

This model is especially useful in residences, offices, schools, shops, small hotels, technical rooms or growing companies, where it is common to have multiple network outlets distributed across different areas. Compared with a 5-port or 8-port switch, the DS-3E0516R-O allows more devices to be connected without having to install several smaller switches, reducing messy cabling and simplifying network maintenance.

Each of its 16 RJ45 ports works at 10/100/1000 Mbps, providing enough capacity for networks with a high density of connections. Its automatic switching helps organise traffic within the local network, allowing each connected device to operate at the right speed and without unnecessarily saturating the installation.

Thanks to its Plug & Play operation, this switch does not require complex configuration: simply connect it to the power supply and link the devices using an Ethernet cable. It is ideal for installers who need to set up a professional rack-mounted wired network, with capacity for current workstations and future expansions, without complicating the commissioning process.

Its fanless metal housing, rack-mounting design, maximum power consumption of up to 12 W and 6 kV surge protection support an organised, silent and reliable installation. It operates between 0 ºC and 40 ºC and supports humidity from 5% to 95% without condensation, making it practical for new installations or professional network expansions. For solutions with power over network cable, you can visit our PoE switches section.

Reference: DS-3E0516R-O

-
+

Extended information about the Hikvision DS-3E0516R-O 16-Port RJ45 1Gbps 12W Switch

Practical applications of the Hikvision DS-3E0516R-O 16-Port RJ45 1Gbps 12W Switch

Example 1. IP video surveillance network in a subtropical fruit trading company:

This switch has been installed in a 19" rack for an IP CCTV system in an industrial warehouse that trades subtropical fruits, with storage areas, cold rooms, loading docks and offices. It allows IP cameras with independent power supply to be connected through a stable, high-performance Gigabit network. Recommended for 24/7 video surveillance systems with NVR recorders and Full HD or 4MP cameras in industrial and logistics environments where reliable and continuous communication is required.

Example 2. Company network with many wired devices:

In an office or small business, the DS-3E0516R-O allows workstations, network printers, NVRs, routers, access points and other Ethernet devices to be connected from a single point. It is a practical solution for growing companies that need a cleaner network structure and available ports for future expansion. Its rack installation makes it easy to integrate into a professional communications cabinet.

Package contents of the Hikvision DS-3E0516R-O 16-Port RJ45 1Gbps 12W Switch

The technical datasheet confirms that the switch is designed for rack installation and uses AC power connected directly to a socket. It also indicates that the device is equipped with mounting ears, a grounding terminal and 100-240 V AC power input. However, the datasheet does not specify the full commercial package contents.

Technical specifications of the Hikvision DS-3E0516R-O 16-Port RJ45 1Gbps 12W Switch

Specification Detail
Brand Hikvision
Model DS-3E0516R-O
Product type Gigabit Plug & Play switch
Number of ports 16 Gigabit RJ45 ports
Speed per port Auto-negotiation 10/100/1000 Mbps
Auto MDI/MDIX Supported
Installation and setup Plug & play design with no configuration required
Switching capacity 32 Gbps
Packet forwarding rate 23.81 Mpps
MAC address table 8 K
Internal cache 4.1 Mbits
Installation Rack-mounted, equipped with mounting ears
Housing Metal housing
Thermal design Fan-free design
Power supply 100-240 V AC, 50/60 Hz, max. 0.3 A
Maximum power consumption 12 W
Idle power consumption 2.8 W
Surge protection 6 kV
Operating temperature 0 °C to 40 °C
Storage temperature -40 °C to 85 °C
Operating humidity 5% to 95%, non-condensing
Dimensions 327 × 44 × 118 mm
Net weight 0.9 kg
Gross weight 1.4 kg
Indicators PWR, working mode and LINK/ACT
Mode button Yes
Grounding terminal Yes
Certifications CE-EMC, RCM, CE-LVD, CB, CE-RoHS, WEEE, REACH
