UTP CAT5E Cable Exterior White CU CPR ECA Coil 305m from Tecatel

Tecatel UTP data cable for outdoor white with UV protection and copper conductors.

What technical specifications does the Tecatel UTP CAB-UTP5CUPEB cable have?

• Number of pairs: 4
• Internal Conductor: Cu
• Conductor diameter: 0.51 mm +/- 0.02 mm
• AWG: 24
• Insulation: Polyethylene, 0.95 mm
• Outer sheath: PE (Polyethylene)
• Outer shell diameter: 5.6 mm +/- 0.2 mm
• Cover Color: White
• Maximum delay (ns / 100m): 540.0
• Rated propagation speed: 69%
• Minimum radius of curvature: 8 x D
• Nominal mutual capacity (1KHz): 56 nF / Km
• Max group delay (100 MHz): <20ns / 100 meters
• Impedance (Ω): 100 ± 15
• Maximum conductor resistance: 9.38 Ω / 100m at 20º C
• Minimum insulation resistance: 150 MΩ / Km
• Test Voltage: 1000 V
• Resistance imbalance: 2% max
• Bandwidth: 100 MHz
• Operating temperature: -20º - + 75º C
• Torn Rope: Yes
• Packaging: Dispensing box
• Type of marking: Marking of meters
• Supply unit: 305 meter coil
• Weight: 8.7 kg
• CPR: Eca
