Wall Rack Cabinet 19" 15U Depth 550 with Accessories GTLAN

SKU

GTL31GTM15F5

Brands: GTlan

Availability: On request

Delivery: 1 to 7 days

€330.79 Tax included

Wall Rack Cabinet 19 "15U Depth 550mm with Accessories GTLAN 31GTM15F5

19" 15U high and 550mm deep wall-mount rack cabinet. Dimensions: 768 (Height) x 600 (Width) x 550 (Depth) mm. Cabinet divided into 2 sections: hinged rear to improve handling by that side.

Made of 2mm SPCC cold rolled steel and tempered glass front door, with rectangular lock. Smooth detachable sides with plastic closures (optional round lock). The cabinet supports a maximum load of 60kg. Ideal for small installations that require a solid and robust rack cabinet.

Accessories included with this wall-mounted rack cabinet: fixed tray, 19" power strip, ceiling fan and screw/nut kit.

Details

Server rack cabinet 19" 15U and 550mm depth, consisting of 2 bodies and accessories.

Click here to discover the entire range of GTLAN rack cabinets.

What technical specifications does the GTLAN 31GTM15F5 rack have?

Capacity	15U
Profile	L type
Maximum load	60 kg
Material	5mm tempered glass, 2mm high quality cold rolled SPPC steel
Clamping profiles	4 pcs adjustable in depth (2mm thick)
Front door	5mm tempered glass with rectangular lock
Back	Folding to improve the handling of the cabinet from the rear of it
Lateral	Detachable smooth with plastic closures (optional round side lock)
Wired input	Upper and lower
Finish	Fine-grained powder coating
Color	Black RAL - 9004
Dimensions	768x600x550 mm
Packaging Dimensions	780x610x560 mm
Weight	29.65 kg
Packaging Weight	32 kg
Accesories	Fixed tray + Power strip 19" + Ceiling fan + kit screws/nuts
Watertightness	IP20
Normative	EIA/ECA-310-E, IEC 60297, ETSI/EN 300 119, RoHS 2011/65/UE Y CE
Cubic capacity with pallet	0.202 m3

More Information

More Information
EAN	8435481002540
Color	Black
Units	15
Width	19"
Depth	550 mm
Rack type	Wall
Rack accessories	Other accessories, Plates, Strips, Ventilation units
Frame	Wall
Product Brand	GTlan
