TVT 4MP Motorized Varifocal 2.8-12mm Bullet IP Camera with 70m IR, MicroSD and AI

SKU
TVT-423
Brands: TVT
€506.51
Tax included
% Discount for professionals
TVT
Availability: On request
1 to 7 days

4MP LPR Bullet IP Camera with 2.8-12 mm Motorized Lens and 70 m IR

The TVT-423 is a 4MP Bullet IP camera designed for license plate identification and recording at vehicle access points. Its LPR technology makes it suitable for barrier control, car parks, toll areas and residential entrances, providing a professional solution for automated vehicle access monitoring within IP video surveillance systems.

Equipped with a 1/1.8" CMOS sensor and 2688 × 1520 resolution, it features a 2.8-12 mm F1.6 motorized varifocal lens, allowing installers to remotely adjust the field of view to accurately cover the required traffic lane. Its infrared illumination provides a range of up to 70 metres, enabling surveillance in very low-light or completely dark environments.

The camera incorporates LPR/ANPR license plate recognition, 120 dB WDR, 3D DNR, HLC, BLC, MicroSD storage up to 256 GB and PoE power supply. Its IP67 weather protection makes it suitable for demanding outdoor installations. These features make it particularly suitable for professional installers who need to combine IP cameras with intelligent vehicle access control.

Designed for new installations and extensions of IP CCTV systems, rather than as a specific replacement part, the TVT-423 combines license plate recognition, motorized optics, long-range IR illumination and outdoor protection in a robust solution for professional vehicle monitoring and access-control projects.

Reference: TVT-423

-
+

Extended information about TVT 4MP Motorized 2.8-12mm LPR IP67 IR70 Bullet IP Camera

Practical applications of the TVT 4MP Motorized 2.8-12mm LPR IP67 IR70 Bullet IP Camera

Example 1. Automated access control in residential communities:

Installed at the entrance lane of a residential complex, the TVT-423 can identify vehicle license plates and compare them with its internal database. Its relay output can form part of a barrier control system, allowing authorised vehicles to enter while maintaining a visual record of incoming and outgoing traffic. The motorized lens helps the installer accurately frame the required lane during commissioning.

Example 2. Vehicle monitoring in car parks and controlled facilities:

In a commercial car park, logistics centre or industrial site, the camera can capture the original 4MP image together with license plate information while recording additional vehicle attributes. Its LPR functions, long-range IR illumination and IP67 housing make it particularly suitable for entrances that must continue operating at night or in demanding outdoor environments.

Package contents of the TVT 4MP Motorized 2.8-12mm LPR IP67 IR70 Bullet IP Camera

  • 1 × TVT TD-9443A3BH-A-LR(D/AZ/PE/AR5) camera

Technical specifications TVT 4MP Motorized 2.8-12mm LPR IP67 IR70 Bullet IP Camera

SKU TVT-423
Manufacturer TVT
Manufacturer model TD-9443A3BH-A-LR(D/AZ/PE/AR5)
Camera type 4MP LPR Bullet Network Camera
Image sensor 1/1.8" CMOS
Maximum resolution 2688 × 1520
Main stream frame rate Up to 30 fps at 4MP
Minimum illumination 0.001 lux @ F1.6, AGC ON; 0 lux with IR
Day/Night ICR auto switch, true day/night
Lens 2.8-12 mm @ F1.6
Lens type Motorized varifocal
Horizontal field of view 100°-48.5°
Vertical field of view 54°-26.5°
Diagonal field of view 119°-55.8°
Recommended ANPR distance 3-8 m
IR distance 50-70 m
Wide Dynamic Range 120 dB
Digital noise reduction 3D DNR
Image functions WDR, BLC, HLC, Defog, ROI
S/N ratio ≥50 dB
Main stream compression H.265+ / H.265 / H.264+ / H.264
Additional stream compression H.265+ / H.265 / H.264+ / H.264 / MJPEG
Number of streams 3
Bit rate 64 Kbps-8 Mbps
Bit rate control VBR / CBR
Audio compression G711A / G711U
Audio 1 input / 1 output
Alarm 1 input / 1 output
Video output CVBS output, BNC × 1
Local storage MicroSD up to 256 GB
Ethernet RJ45 10/100 Mbps
PoE IEEE 802.3af
ONVIF Yes
RS485 Yes
Wiegand Yes, 26-bit
LPR / ANPR Yes
License plate database Up to 10,000 plates
Vehicle detection Vehicles with and without license plates
LPR functions Plate exposure, travel direction, plate comparison and character fault tolerance
Vehicle feature extraction Vehicle colour, plate colour, vehicle type and brand/model
Capture speed range 0-80 km/h for 2.8-12 mm version
Vehicle capture rate ≥99% under recommended conditions
LPR accuracy – Entrance/Exit ≥99% under recommended conditions
LPR accuracy – Road ≥98% under recommended conditions
Barrier gate control Camera or platform control
Relay output 1-channel barrier control output
Screen connection RS485 supported
Remote monitoring Web browser / TVT NVMS2.0 / NVR / Mobile App
Network protocols UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTMP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, HTTP POST, 802.1x, UPnP, HTTPS, P2P, QoS
Power supply 12 VDC / 24 VAC / PoE
Power consumption <12 W DC; <10 W AC; <10 W PoE
Protection rating IP67
Operating temperature -30 °C to +60 °C
Storage temperature -30 °C to +65 °C
Humidity <95%, non-condensing
Dimensions 278.3 × 100.2 × 88.7 mm
Net weight Approx. 1.176 kg
Mounting Wall or ceiling
Adjustment Pan 0°-360° / Tilt 0°-90° / Rotation 0°-360°
Certifications CE, FCC
Intended use New IP CCTV and vehicle access-control installations
More Information
More Information
Hight 0.100
Length 0.300
Width 0.100
Technology IP
Usar stock disponible No
Product Brand TVT
Camera Type Bullet
Optic Type Motorized Varifocal
Color White
Alimentación 12VDC/PoE
