TP-Link 16-Port RJ45 1Gb Switch

SKU
TL-SG116E
Brands: Tplink
€72.36
Tax included
Availability: In stock
1 to 7 days

Easy Smart Gigabit TP-Link TL-SG116E Switch for professional high-performance networks

The TP-Link TL-SG116E is a reliable and efficient solution for expanding Gigabit Ethernet networks in professional environments and advanced home installations. Its robust metal housing, silent operation and stable connectivity make it an excellent choice for installers looking for performance, simplicity and reliability in every project.

This semi-managed switch features 16 RJ45 1Gb ports capable of delivering fast and stable data transfers for IP cameras, WiFi access points, video surveillance systems, NAS servers and corporate networks. Thanks to its smart management via web interface and downloadable utility, advanced network features can be configured quickly and easily.

The Plug and Play design allows immediate installation without prior configuration, reducing deployment time in both new installations and existing network expansions. In addition, Green Ethernet technology automatically optimizes power consumption based on cable length and connection status, helping reduce energy costs in continuous operation environments.

The TP-Link TL-SG116E is especially suitable for telecom installers, IP surveillance integrators and small businesses that require a stable 1Gb network, basic management functions and low power consumption. Compatible with standard Ethernet infrastructures, it can be used for both new deployments and network upgrades.

In summary, this Easy Smart Gigabit switch combines high-speed connectivity, easy installation and essential management features in a compact professional design, ideal for modern wired network installations.

Reference: TL-SG116E

-
+

Extended information about TP-Link 16-Port RJ45 1Gb Switch

Practical applications of the TP-Link 16-Port RJ45 1Gb Switch

Example 1. Installation of 16 IP cameras in an outdoor parking area:

The Extend Mode of the TP-Link TL-SG1210PP allows IP cameras located up to 250 meters from the switch to be powered and connected using a single Ethernet cable. This feature is especially useful in parking areas, as a pair of switches can be used to extend connectivity for up to 16 IP cameras. Thanks to the uplink ports, one switch can be connected to another without losing functionality on any of the connected cameras.

Example 2. Network distribution in offices and small businesses:

In offices, technical workspaces and small businesses, this semi-managed switch provides a fast and efficient solution for connecting computers, network printers, IP phones, WiFi access points and NAS servers. Plug and Play installation reduces setup time, while Green Ethernet technology helps lower daily power consumption.

Package contents of the TP-Link 16-Port RJ45 1Gb Switch

  • TP-Link TL-SG116E switch
  • Power adapter
  • Quick installation guide
  • Rubber feet for desktop installation
  • Rack mounting kit
  • Manufacturer documentation

Technical specifications TP-Link 16-Port RJ45 1Gb Switch

Specification Details
Brand TP-Link
Model TL-SG116E
Product type Easy Smart semi-managed switch
Number of ports 16 RJ45 1Gb ports
Network speed 1Gb
Switching capacity 32 Gbps
Packet forwarding rate 23.8 Mpps
MAC address table 8K entries
Jumbo Frame 10 KB
Smart features VLAN, QoS, IGMP Snooping, Port Mirroring, Loop Prevention
Management Web interface and downloadable Easy Smart Configuration Utility
Installation Plug and Play, no configuration required
Energy-saving technology Green Ethernet automatic power saving
Housing material Metal
Mounting Desktop or rack installation
Cooling Fanless design
Power supply 100-240V AC, 50/60Hz
Maximum power consumption 9.19 W
Dimensions 286 x 111.7 x 25.4 mm
Supported standards IEEE 802.3i, 802.3u, 802.3ab, 802.3x
Compatibility Professional and residential Gigabit Ethernet networks
Recommended use New installations and network expansions
Colour Black
SKU TL-SG116E
More Information
Hight 0.000
Length 0.000
Width 0.000
REDES - System NOT POE
REDES - SERIE 16 Ports
Color Black
Network Equipment Switch
Ports 16
Data Speed Gigabit (10/100/1000Mbps)
PoE No
Usar stock disponible No
Product Brand Tplink
Write Your Own Review
You're reviewing:TP-Link 16-Port RJ45 1Gb Switch
Your Rating
File Label Size Download
pdf Ficha Técnica Switch 16 Puertos RJ45 1Gb de Tp-Link 2.4 MB Download
