| Brand |
TP-Link VIGI |
| Model |
InSight S485 |
| SKU |
TL-INSIGHT-S485-4MM |
| Camera Type |
Turret Network Camera |
| Image Sensor |
1/2.7" Progressive Scan CMOS |
| Maximum Resolution |
3840 × 2160 pixels |
| Lens Type |
Fixed focal lens |
| Focal Length |
4 mm |
| Aperture |
F1.6 |
| Lens Mount |
M12 × P0.5 |
| Horizontal Field of View |
91.5° |
| Vertical Field of View |
46.1° |
| Diagonal Field of View |
109.6° |
| DORI Detection Distance |
107 m |
| DORI Observation Distance |
44 m |
| DORI Recognition Distance |
21 m |
| DORI Identification Distance |
11 m |
| Minimum Illumination |
0.005 Lux; 0 Lux with IR/White light |
| Shutter Speed |
1/3 to 1/10000 s |
| Day/Night Mechanism |
IR Cut Filter |
| IR LEDs |
4 |
| IR Range |
Up to 30 m |
| IR Wavelength |
850 nm |
| White LEDs |
4 |
| White Light Range |
Up to 30 m |
| Illuminator Control |
Auto / Scheduled / Always On / Always Off |
| Manual Pan Adjustment |
0° to 360° |
| Manual Tilt Adjustment |
0° to 75° |
| Manual Rotation Adjustment |
0° to 360° |
| Main Stream Frame Rate |
Up to 25 fps |
| Main Stream Resolutions |
3840×2160, 2560×1440, 2304×1296, 2048×1280, 1920×1080, 1280×720 |
| Sub-Stream Resolutions |
848×480, 704×576, 640×480, 640×360, 352×288, 320×240 |
| Video Compression |
Main stream: H.265 / H.265+ / H.264 / H.264+; Sub-stream: H.265 / H.264 |
| Main Stream Bit Rate |
256 Kbps to 8 Mbps |
| Sub-Stream Bit Rate |
64 Kbps to 512 Kbps |
| Wide Dynamic Range |
120 dB |
| SNR |
≥ 52 dB |
| Image Enhancement |
BLC / 3D DNR / HLC / SmartIR |
| Privacy Mask |
Up to 4 masks |
| ROI |
1 region |
| Human & Vehicle Classification |
Yes |
| Smart Events |
Intrusion, line-crossing, region entering, region exiting, abandoned object, object removal, loitering, people, vehicle, abnormal sound and scene change detection |
| Basic Events |
Motion detection, video tampering detection and illegal login exception |
| Alarm Linkage |
Memory card recording, message push, audible warning and white light flashing |
| Two-Way Audio |
Yes |
| Built-in Microphone |
Yes, up to 5 m recording radius specified by manufacturer |
| Built-in Speaker |
Yes |
| Audio Sampling Rate |
8 kHz |
| Audio Bit Rate |
64 Kbps (G.711 alaw) |
| Network Interface |
1 × RJ45 10/100M self-adaptive Ethernet port |
| PoE |
802.3af/at, Class 0 |
| ONVIF |
Yes, Profile S/T/G |
| Network Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP |
| Supported Clients |
VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client |
| Cloud Support |
Yes |
| On-board Storage |
MicroSD card slot, up to 512 GB |
| MicroSD Card Included |
No |
| Power Supply |
12V DC ± 5% |
| Maximum DC Power Consumption |
11.5 W |
| Maximum PoE Power Consumption |
12.5 W |
| Material |
Metal |
| Protection Rating |
IP67 |
| Operating Temperature |
-30 °C to 60 °C |
| Operating Humidity |
95% or less, non-condensing |
| Dimensions |
111 × 111 × 83.7 mm |
| Net Weight |
0.48 kg |
| Certifications |
CE, NTRA, VCCI, KC, BSMI, FCC, IC |
