Hikvision 32-Channel IP 12MP NVR Recorder with PoE and Motion Detection 2.0

SKU
HWN-5232MH-16P(D)
Brands: Hikvision
€419.87
Tax included
% Discount for professionals
Hikvision
Availability: In stock
1 to 7 days

Hikvision HWN-5232MH-16P(D) 32-Channel IP 12MP NVR with PoE and Motion Detection 2.0

The Hikvision HWN-5232MH-16P(D) is a professional NVR recorder for IP video surveillance installations that need to centralise up to 32 cameras with high performance. It is a very complete solution for buildings, residential communities, companies, industrial warehouses and projects where the installer needs expansion capacity, remote management and a reliable recording infrastructure within the HiWatch range.

This NVR works in IP security systems and supports recording resolution up to 12 MP, with H.265+/H.265/H.264+/H.264 compression to optimise storage. Its 256 Mbps incoming bandwidth and 160 Mbps outgoing bandwidth allow it to manage demanding installations in NVR recorder projects with multiple IP cameras.

The integrated PoE power supply using the IEEE 802.3af/at standard allows up to 16 PoE cameras to be connected and powered directly from the recorder, reducing cabling, external power supplies and installation time. The remaining cameras can be integrated through the network using additional switches, making it easier to centralise image capture, video recording and power distribution in large professional installations.

The HWN-5232MH-16P(D) is not a spare part, but a main unit for new installations or expansions of IP video surveillance with PoE cameras. Thanks to AcuSense, Motion Detection 2.0, human/vehicle analysis, 128 remote connections, 4K HDMI output, 4/1 alarm input/output and ONVIF support, it fits very well in Hikvision CCTV projects where local control, remote access and false alarm reduction are required.

Reference: HWN-5232MH-16P(D)

-
+

Extended information about the HWN-5232MH-16P(D) Hikvision 32-Channel IP 12MP NVR with Motion Detection 2.0

Practical applications of the HWN-5232MH-16P(D) Hikvision 32-Channel IP 12MP NVR with Motion Detection 2.0

Example 1. Centralised IP video surveillance for buildings, residential communities or companies:

In an installation with multiple control areas, entrances, garages, corridors and common areas, the HWN-5232MH-16P(D) allows up to 32 IP cameras to be centralised from a single recorder. Its 16 integrated PoE ports make it easier to power cameras directly from the NVR, while the remaining cameras can be added through the existing network. This architecture is very useful for buildings, residential communities and companies that need an organised, scalable and easy-to-monitor installation.

Example 2. Professional remote control with local access via 4K HDMI:

In projects where the customer needs to review cameras from different locations, this NVR allows up to 128 remote connections and access via browser, software or mobile app. In addition, the 4K HDMI output allows a monitor to be connected directly to the recorder to view cameras locally without relying on external equipment. This combination makes the installer’s work easier and gives the user flexible monitoring both on site and remotely.

Package contents of the HWN-5232MH-16P(D) 32-ch PoE 1U K Series AcuSense 4K NVR

Recommended contents to be published after confirmation with the supplier or warehouse:

  • Hikvision HWN-5232MH-16P(D) NVR recorder
  • Power cable
  • USB mouse
  • Product documentation or quick start guide
  • Basic connection accessories included by the manufacturer/distributor depending on the batch

Internal note: the distributor datasheet indicates a mouse and space for 2 HDDs, but it does not specify all included accessories. It is advisable to confirm the final package contents with the supplier or warehouse before publishing.

Technical specifications HWN-5232MH-16P(D) 32-ch PoE 1U K Series AcuSense 4K NVR

Specification Value
Brand Hikvision
Model HWN-5232MH-16P(D)
Product type IP PoE NVR recorder
Series HiWatch / K Series AcuSense
IP channels Up to 32 channels
IP video inputs 32 channels
PoE ports 16 RJ-45 10/100 Mbps ports
PoE standard IEEE 802.3af/at
PoE power ≤ 200 W according to the official Hikvision datasheet
Incoming bandwidth 256 Mbps
Outgoing bandwidth 160 Mbps
Recording resolution 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Decoding formats H.265, H.265+, H.264+, H.264
Decoding capacity with AI enabled 1 channel at 12 MP/30 fps, 2 channels at 8 MP/30 fps, 4 channels at 4 MP/30 fps or 8 channels at 1080p/30 fps
Decoding capacity with AI disabled 2 channels at 12 MP/30 fps, 3 channels at 8 MP/30 fps, 6 channels at 4 MP/30 fps or 12 channels at 1080p/30 fps
Synchronous playback 16 channels
Device-based intelligence Facial recognition, perimeter protection and Motion Detection 2.0
Camera-based intelligence Facial recognition, perimeter protection, objects thrown from buildings, Motion Detection 2.0, ANPR and VCA
Motion Detection 2.0 Device-based on all channels up to 4 MP; up to 8 MP with enhanced SVC mode
Perimeter protection 2 channels, 4 MP, with human/vehicle analysis to reduce false alarms
Facial recognition Face comparison, face capture and face image search
Face library Up to 16 libraries, up to 20,000 images in total
Face picture comparison 4 channels
HDMI output 1 channel, up to 4K 3840 × 2160 at 30 Hz
VGA output 1 channel, up to 1920 × 1080 at 60 Hz
Video output mode Independent HDMI/VGA output
Audio output 1 RCA channel
Two-way audio 1 RCA channel
Remote connections Up to 128
API compatibility ONVIF Profile S/G, SDK, ISAPI
Compatible browsers IE11, Chrome V57, Firefox V52, Safari V12, Edge V89 or later versions
Network protocols TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Network interface 1 RJ-45 10/100/1000 Mbps self-adaptive port
SATA interface 2 SATA interfaces
Disk capacity Up to 10 TB per HDD according to the official Hikvision datasheet
USB interface 1 × front USB 2.0 and 1 × rear USB 2.0
Alarms 4 inputs / 1 output
Power supply 100 to 240 VAC, 50 to 60 Hz
Consumption ≤ 15 W without HDD and with PoE disabled
Working temperature -10 °C to 55 °C
Working humidity 10% to 90%
Dimensions 385 × 315 × 52 mm
Weight ≤ 3 kg without HDD
CE certification EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:2017
Other certifications CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS

Technical note: the supplied distributor datasheet indicates 2 SATA HDDs up to 6 TB, while the official Hikvision datasheet for the HWN-5232MH-16P(D) model indicates up to 10 TB per HDD. It is recommended to confirm this detail with the supplier before publishing the final storage capacity.
