A neighborhood supermarket uses this NVR to manage 8 IP cameras, taking advantage of its 4K resolution at the checkout counter to monitor cash handling with exceptional clarity. The cameras covering the aisles and warehouse are configured with the recorder’s H.265+ codec, reducing video file sizes and allowing more recording time to be stored across its two internal hard drives. Outside business hours, the manager enables motion detection in the loading area; if the system detects a human figure during the night, it can generate an alert through Hik-Connect, depending on the camera, firmware and notification settings used.
In offices, residential properties, apartment buildings or small companies, this 8-channel NVR can manage indoor and outdoor IP cameras from a single location. Its 4K HDMI output provides high-resolution local monitoring, while Hik-Connect enables remote access to the system when network access and security settings have been configured correctly.
| Product identification | |
|---|---|
| Brand | Hikvision |
| Model | HWN-4208MH(E) |
| Available model | HWN-4208MH(E)(STD) |
| SKU | HWN-4208MH |
| Product type | 8-channel Network Video Recorder |
| Chassis format | 1U |
| Motion detection | Motion Detection 2.0 |
| Human and vehicle analysis | Up to 4 channels |
| IP video inputs | 8 channels |
| Incoming bandwidth | 80 Mbps |
| Outgoing bandwidth | 80 Mbps |
| HDMI output | 1 channel: 3840 × 2160 at 30 Hz 1920 × 1080p at 60 Hz 1600 × 1200 at 60 Hz 1280 × 1024 at 60 Hz 1280 × 720 at 60 Hz 1024 × 768 at 60 Hz |
| VGA output | 1 channel: 1920 × 1080p at 60 Hz 1600 × 1200 at 60 Hz 1280 × 1024 at 60 Hz 1280 × 720 at 60 Hz |
| Video output mode | Simultaneous HDMI and VGA output |
| Audio output | 1 × RCA channel, linear, 1 kΩ |
| Two-way audio | 1 × RCA channel, 2.0 Vp-p, 1 kΩ |
| Decoding formats | H.265+, H.265, H.264+ and H.264 |
| Recording resolutions | 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF and QCIF |
| Synchronous playback | 8 channels |
| Specified decoding capacity | Up to 2 channels at 8MP, 4 channels at 4MP or 8 channels at 1080p |
| Decoding with AI and 4K disabled | 8 channels at 1080p and 30 fps |
| Decoding with AI or 4K enabled | 6 channels at 1080p and 30 fps |
| Resolution limitation per stream | The length or width of each camera stream resolution cannot exceed 4096 pixels |
| Remote connections | Up to 32 |
| Network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™ and HTTPS |
| Network interface | 1 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
| SATA interfaces | 2 |
| Maximum capacity per drive | Up to 8TB per drive |
| Maximum possible raw capacity | Up to 16TB using 2 × 8TB drives, not included |
| USB interfaces | 2 × USB 2.0 |
| Rear connections | LAN interface Audio output Audio input HDMI output VGA output USB ports 12VDC power input GND terminal Power switch |
| Power supply | 12VDC or ≤ 40W, according to the manufacturer’s specification |
| Recorder power consumption | ≤ 10W |
| Operating temperature | −10°C to +55°C |
| Operating humidity | 10% to 90% |
| Dimensions | 384 × 223 × 48 mm |
| Weight | ≤ 2.6 kg |
| Specified CE standards | EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3 and EN 50130-4 |
| EAN | 6941264083085 |
|---|---|
| Hight | 0.500 |
| Length | 0.450 |
| Width | 0.450 |
| Included | Mouse, Power supply |
| Event notifier | No |
| No. CCTV Recorder Inputs | 8 IP |
| Audio in ports | 1 |
| Usar stock disponible | No |
| Product Brand | Hikvision |
| Integrated PoE Ports | non-PoE |
| Supported IP Channels | 8 |
| Maximum Camera Resolution | 8 Mpx |
| Number of Supported Hard Drives | 2 |
| Maximum HDD Capacity | 6 TB |
| Hard Drive Included | Not Included |
| Intelligent Analytics | Motion detection |
| Wi-Fi | With Wi-Fi |
| File | Label | Size | Download |
|---|---|---|---|
|
fICHA tÉCNICA Grabador NVR para Cámaras IP 8 Canales 8Mpx POE | 407.1 KB | Download |
