Multimode Fiber Optic Pigtail OM4 0.9mm Simplex SC/PC LSFH 2m

SKU
TEL230911
Brands: Televes
Availability: On request
1 to 7 days
€4.50 Tax included
-
+

OM4 Singlemode Pigtail with SC/PC connector from Televes

This fiber optic pigtail allows the transmission of optical signal from one device to another, separated from each other by a distance of 2 meters.

This fiber optic pigtail is used to connect one end using the SC/PC connector and the other end to splice to the fiber of the main cable. Its 900μm cover is LSFH halogen-free, suitable for indoors.

This pigtail comes with a free end and the cable in magenta, the cable type is multimode OM4 ITU-T G.651.1.

Technical Specifications of the OM4 Single-mode Pigtail with SC/PC connector from Televes



Fiber core type   Multi-mode (ITU-T-G.651.1)
Optical fiber type category   OM4
Fiber core diameter μm 50
Fiber cladding diameter μm 125
Coating buffer diameter μm 250
Outer sheath Diameter mm 0.9
Outer sheath Material   LSFH
Blocking jelly   No
Insertion losses in connector 1 dB < 0.3
Return losses in connector 1 dB > 30
Optical connector type 1   SC
Polishing type (Optical connector 1)   PC
Minimum bending radius mm 4.5
Operating temperature °C -20 ... 70
More Information
EAN 8424450273814
System Multimode
Serie 2m
Fiber type Multimode
Entorno Interior
Color Pink
Product Brand Televes
