Switch 18 Ports 1Gbps 16 POE+ 250W from Tp-Link

SKU
TL-SG1218MP
Brands: Tplink
€190.60
Tax included
Tplink
Availability: On request
1 to 7 days

18 Port (16 POE) Gigabit IP Switch from Tp-Link

Looking for a robust switch to power IP cameras, WiFi hotspots or VoIP phones without the hassle of extra cables? The Tp-Link SG1218MP is an 18-port switch with 16 Gigabit RJ45 PoE+ ports capable of supplying direct power (up to 30W per port), eliminating the need for external adapters or injectors.

This switch is intended for enterprise, office or security installations requiring reliability and high bandwidth. With a total PoE budget of 250W, you can seamlessly connect multiple IP cameras, APs or PoE+ devices without worrying about outages or overloads.

In addition, it has 2 SFP slots that facilitate expansion with fiber optic links, perfect for interconnecting different rooms, buildings or simply ensure maximum speed to a main server.

Where can you use it? From setting up a video surveillance network in an industrial building, to deploying professional WiFi in a hotel or coworking space. It's plug & play, plug and play, but with intelligent features such as priority detection and automatic recovery of failed PoE devices.

Can I connect cameras of different brands? Of course, the PoE+ standard IEEE 802.3af/at is compatible with most cameras and APs on the market.

Package contents:

  • 1 × TP-Link SG1218MP Switch

  • Power cable

  • Rack mounting kit

  • Quick installation manual

With the SG1218MP switch, your network will be faster, safer and simpler - the ally your business needs!

Technical Specifications of the Tp-Link 18 Port (16 POE) Gigabit IP Switch

Parameter

Specification

Brand

TP-Link

Reference

SG1218MP

RJ45 Ports

16 × Gigabit PoE+

SFP Ports

2 × 1000 Mbps

PoE Standards

IEEE 802.3af/at

Total PoE Power Budget

192 W

Max power per port

Up to 30 W

Switching capacity

36 Gbps

MAC Address Table

8 K entries

Extra features

Auto PoE recovery, QoS, IGMP Snooping

Mounting

19" rack or desktop

Max power consumption

<220 W

Dimensions

440 × 180 × 44 mm

Weight

Approx. 2.5 kg





































Specs

  • Hardware features
    • Standards and protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p
    • Interface: 16 RJ45 PoE + gigabit ports, 2 RJ45 gigabit non-PoE ports, 2 gigabit SFP combo slots
    • Network media: 10BASE-T UTP cable category 3, 4, 5 (max 100 m), EIA/TIA-568 100? STP (max 100 m), 100BASE-TX: UTP cable category 5, 5e (max 100 m), EIA/TIA-568 100ohm STP (max 100 m), 1000BASE-T UTP cable category 5, 5e, 6 or higher (max 100 m), EIA/TIA-568 100ohm STP (max 100 m), 1000BASE-X MMF, SMF
    • Fan Quantity: 2
    • Physical security lock: Yes
    • Power supply: 100-240 VAC, 50/60 Hz
    • PoE+ Ports (RJ45): Standard: 802.3at/802.3af compliant
    • PoE Ports: Ports 1–16
    • PoE Power Budget: 250 W
    • Dimensions (W x D x H): 17.3 × 7.1 × 1.73 in (440 × 180 × 44 mm)
    • Mounting: 1U 19” rack mount
    • Maximum power consumption: 21.4 W (no power supply device connected), 286.6 W (with 250 W power supply devices connected)
    • Maximum heat dissipation: 73.0 BTU/h (without PD connected), 977.4 BTU/h (with 250W PD connected)
  • Performance
    • Switching capacity: 36 Gbps
    • Packet forwarding speed: 26.78 Mbps
    • Address Table: MAC 8K
    • Packet buffer memory: 4.1 Mbit
    • Advanced Features: Supports IEEE 802.3af/at compliant PDs, 802.1p/DHCP QoS, MAC address auto-learning and auto-aging, IEEE802.3x Flow Control for full-duplex mode and backpressure for half-duplex mode
    • Giant plot: 10 KB
  • Others
    • Certification: CE, FCC, RoHS
  • Around
    • Operating temperature: 0–50 °C (32–122 °F)
    • Storage temperature: -40–70 °C (-40–158 °F)
    • Operating humidity: 10 to 90% relative humidity non-condensing
    • Storage humidity: 5–90% relative humidity non-condensing
More Information
EAN6935364072209
Hight0.130
Length0.120
Width0.200
REDES - SystemPOE+
REDES - SERIE16 Ports
ColorBlack
Network EquipmentSwitch
Ports18
Data SpeedGigabit (10/100/1000Mbps)
PoEYes
Product BrandTplink
Write Your Own Review
You're reviewing:Switch 18 Ports 1Gbps 16 POE+ 250W from Tp-Link
Your Rating
File Label Size Download
pdf Ficha Técnica Switch 18 Puertos 1Gbps 16 POE+ 250W de Tp-Link 1.3 MB Download
