Ajax Wireless Rate-of-Rise Heat and CO Detector with Built-in Siren – Black

SKU
AJ-FIREPROTECT2-HC-SB-B
Brands: AJAX
€131.03
Tax included
Availability: In stock
5 days

Ajax FireProtect 2 Wireless Heat and CO Detector with Built-in Siren – Black

The Ajax FireProtect 2 SB (Heat/CO) Jeweller provides protection against two critical indoor hazards: abnormal temperature increases and carbon monoxide accumulation. Its wireless operation, built-in siren and long-life batteries provide a reliable detection solution with reduced maintenance requirements.

Unlike other FireProtect 2 models, this version does not include a smoke sensor. It uses two A1R-class thermistors to trigger an alarm when the temperature exceeds +64 °C or rises by more than 10 °C within one minute, together with a dedicated chemical sensor for detecting dangerous CO concentrations.

The detector communicates via Jeweller wireless technology, providing a range of up to 1,700 metres in open space, and features a built-in 85 dB siren for local audible warning. It is particularly suitable for installers protecting kitchens, technical rooms or areas containing combustion equipment as part of a professional Ajax alarm system, where optical smoke detection is not required.

The SB (Sealed Batteries) version features two integrated lithium batteries with a service life of up to 10 years, helping minimise maintenance. It is designed for new installations and extensions of compatible Ajax systems; it is not a replacement part. If the project also requires optical smoke detection, a Ajax smoke, heat and CO detector from the same range can be used instead.

Reference: AJ-FIREPROTECT2-HC-SB-B

-
+

Expanded information about Ajax Wireless Heat and CO Detector with Built-in Siren – Black

Practical applications of Ajax Wireless Heat and CO Detector with Built-in Siren – Black

Example 1. Protection of kitchens, boiler rooms and areas with combustion equipment:

In a kitchen, boiler room or indoor area containing combustion appliances, the Ajax FireProtect 2 SB (Heat/CO) Jeweller can simultaneously monitor abnormal temperature changes and potentially dangerous carbon monoxide concentrations. Because this version does not incorporate an optical smoke sensor, it is especially suitable for projects where heat and CO detection are required without relying on smoke detection. The integrated 85 dB siren provides an immediate local warning if a hazardous condition is detected.

Example 2. Wireless extension of an Ajax fire protection system:

In a home, office or commercial installation already equipped with a compatible Ajax system, the detector can be added without installing dedicated communication wiring. Jeweller technology provides a wireless range of up to 1,700 metres in open space, while the integrated batteries offer up to 10 years of operation. This combination makes the detector particularly useful for installers seeking to extend fire and CO protection while reducing installation work and periodic maintenance.

Package contents of FireProtect 2 SB (Heat/CO) Jeweller

  • 1 × FireProtect 2 SB (Heat/CO) Jeweller detector with integrated lithium batteries
  • 1 × SmartBracket mounting panel
  • 1 × installation kit
  • 1 × quick start guide

Technical specifications Ajax FireProtect 2 SB (Heat/CO) Jeweller

Brand Ajax
Model FireProtect 2 SB (Heat/CO) Jeweller
SKU AJ-FIREPROTECT2-HC-SB-B
Device type Wireless heat and carbon monoxide detector
Application Indoor fire and carbon monoxide protection
Smoke detection No
Heat detection Yes
Heat sensors 2 × A1R-class thermistors
High-temperature alarm Above +64 °C
Rate-of-rise detection Temperature increase of more than 10 °C within 1 minute
Carbon monoxide detection Yes
CO sensor Integrated chemical sensor
CO sensor service life Up to 10 years
Built-in siren Yes
Siren volume 85 dB
Wireless technology Jeweller
Communication range Up to 1,700 m in open space
Maximum effective radiated power Up to 20 mW
Radio frequency bands 866.0–866.5 MHz / 868.0–868.6 MHz / 868.7–869.2 MHz / 905.0–926.5 MHz / 915.85–926.5 MHz / 921.0–922.0 MHz, depending on sales region
Interconnected fire alarm support Yes
Status indication LED
System supervision Regular polling and automatic detector self-diagnostics
Power supply 2 × integrated lithium batteries
Battery type Sealed, non-replaceable
Battery life Up to 10 years
Operating temperature 0 °C to +50 °C
Operating humidity Up to 80%
Protection rating IP20
Dimensions 44 × 86 × 86 mm
Weight 145 g
Colour Black
Mounting SmartBracket mounting panel
Configuration QR code pairing and configuration via Ajax app
EN standard EN 50291-1:2018
Additional standards / certifications indicated by manufacturer BS 5839-6 (Grade F1), BS 5446-2:2003, BSI Kitemark Carbon Monoxide Alarms KM 797661, BSI Kitemark Heat Alarms KM 797644
